(Continued)
ItemNumber
A bag with the following screws and washers for rack-mounting:
Four large screws to attach the brackets to the rack (two screws for each side).
Four medium-sized screws to attach the brackets to the rack (two screws for each side).
Four washers.
Eight small screws to attach the brackets to the switch (four small screws for each side).
Note: Depending on the type of rack, use either the large screws or the medium-sized screws to
attach the brackets to the rack.
6
Rubber feet for desktop or table installation.7
Two large brackets for mounting to a rack.8
Two small brackets for mounting to a rack.9
5.
If any item is missing or damaged, contact your local NETGEAR reseller for
replacement.
Step 4: Mount or place the switch
You can mount the switch in a standard 19-inch (48.26-centimeter) network equipment
rack or place the switch on a flat surface.
Mount the switch in a rack
To install the switch in a rack, you need the 19-inch rack-mount kit supplied with the
switch:
Brackets. Depending on how you install the switch in the rack, either use the small
brackets to mount the switch with its front panel facing you (see the following figure)
or use the large brackets to mount the switch slightly recessed with its back panel
facing you.
Screws. Depending on the rack, use either the large screws or the medium-sized
screws to attach the brackets to the rack.
Hardware Installation Guide35Installation
