NETGEAR AV Series Hardware Installation Guide

The type of fiber ports depends on the model:
- Model M4250-10G2F-PoE+. Two 1GBASE-X SFP ports.
- Model M4250-10G2XF-PoE+. Two 10GBASE-X SFP+ ports
- Model M4250-10G2XF-PoE++. Two 10GBASE-X SFP+ ports
•
AC power receptacle and On/Off power switch. The AC receptacle accepts input
power of 100–240V ~ 50–60 Hz. The amperage depends on the model:
- Model M4250-10G2F-PoE+. 2.25–3.5A.
- Model M4250-10G2XF-PoE+. 5A.
- Model M4250-10G2XF-PoE++. 10A.
LEDs of the 8-port PoE+ and PoE++ models
This section describes the LED designations of the 8-port PoE+ and PoE++ models.
The system LEDs and ports LEDs on the back panel are replicated on the front panel.
(The exception are the port LEDs for the OOB port, which are not replicated on the front
panel.)
The LEDs are clearly named or numbered on the front panel and the back panel.
Table 1. LEDs of the 8-port PoE+ and PoE++ models
DescriptionLED
System LEDs
Solid green. The switch is powered on and operating normally.
Solid yellow. The switch is starting.
Off. Power is not supplied to the switch.
Power LED
Solid green. The fans are functioning normally.
Solid yellow. One or more fans are malfunctioning.
Fan LED
Off. Sufficient (more than 7W of) PoE power is available.
Solid yellow. Less than 7W of PoE power is available.
Blinking yellow. At least once during the previous two minutes, less than 7W
of PoE power was available.
POE LED
Hardware Installation Guide16Hardware Overview
AV Line of Fully Managed Switches M4250 Series

NETGEAR AV Series Specifications

General

Model	AV Series
Switching Capacity	Varies by model
Quality of Service	Yes
Jumbo Frame Support	Yes
Energy Efficient Ethernet	Yes
Ports	5, 8, 16
Layer	Layer 2
Mounting	Desktop
Speed	Gigabit Ethernet
Power Budget	Varies by model
Fanless Design	Yes
