Manage the WAN and LAN Network Settings
198
AC1600 WiFi VDSL/ADSL Modem Router Model D6400
physical WAN interfaces, see Change the Physical WAN Connection Preference on
page 197.
The modem router uses virtual interface WAN1 for regular Internet service. The modem
router can use virtual interface WAN2 for Internet Protocol television (IPTV) service. By
default, interface WAN1 is enabled and interface WAN2 is disabled. In most cases, if you are
not subscribed to IPTV service, you do not need to enable interface WAN2.
If your ISP provides IPTV service in addition to regular Internet service and you are
subscribed to IPTV, you might need to configure and enable interface WAN2.
You might also
need to configure one or more VLANs and set up a bridge:
• For information about configuring VLANs, see Enable and Configure a VLAN on
page 199.
• For information about setting up a bridge, see Set Up a Bridge for a Port Group or VLAN
Tag Group on page 201
 To enable virtual interface WAN 2:
1. Launch an Internet browser from a computer or WiFi device that is connected to the
network.
2. T
ype http://www.routerlogin.net.
A login screen displays.
3. Enter the modem router user name and password.
The user name is admin
.
The default password is password.
The user name and
password are case-sensitive.
4. Click the OK button.
The BASIC Home screen displays.
5. Select Internet.
