Manage the WAN and LAN Network Settings
199
AC1600 WiFi VDSL/ADSL Modem Router Model D6400
The previous figure shows only the top of the Internet Setup screen.
6. From the menu below DSL mode, select WAN2
.
7. Select the Enable This Interface check box.
By default, the Enable This Interface check box is selected for interface W
AN1 but
cleared for interface W
AN2.
8. Click the Apply button.
Your settings are saved.
Enable and Configure a VLAN
A network of computers and devices can behave as if they are connected to the same
network even though they might actually be physically on different segments of a LAN. Virtual
LANs (VLANs) are configured through software rather than hardware, which makes them
very flexible.
If you enable a VLAN and if the network devices (hubs and switches) on your LAN support
the VLAN (802.1Q) standard, the VLAN ID for the wireless access point is associated with all
traffic coming from the modem router.
If you are subscribed to IPTV service, the modem router might require VLAN tags to
distinguish between the Internet traffic and IPTV traf
fic.
Note: If your ISP provides directions on how to set up VLANs for IPTV and
Internet service, follow those directions.
 To enable and configure a VLAN for interface WAN1 and another VLAN for interface
WAN2:
1. Launch an Internet browser from a computer or WiFi device that is connected to the
network.
2. Type http://www
.routerlogin.net.
A login screen displays.
3. Enter the user name and password for the modem router.
The user name is admin.
The default password is
password. The user name and
password are case-sensitive.
4. Click the OK button.
The BASIC Home screen displays.
5. Select Internet.
To Next Page
