Manage the WAN and LAN Network Settings
201
AC1600 WiFi VDSL/ADSL Modem Router Model D6400
Set Up a Bridge for a Port Group or VLAN Tag Group
Some devices, such as an IPTV, cannot function behind the modem router’s network address
translation (NAT) service or firewall. Based on what your Internet service provider (ISP)
requires, for the device to connect to the ISP’s network directly, you can enable the bridge
between the device and the modem router’s Internet port or add new VLAN tag groups to the
bridge.
Note: If your ISP provides directions on how to set up a bridge for IPTV and
Internet service, follow those directions.
Set Up a Bridge for a Port Group
If the devices that are connected to the modem router’s Ethernet LAN port or WiFi network
include an IPTV device, your ISP might require you to set up a bridge for a port group on
interface WAN1.
A bridge with a port group prevents packets that are sent between the IPTV device and the
modem router’s Internet port from being processed through the
modem router’s network
address translation (NAT) service.
 To configure a port group and enable the bridge:
1. Launch an Internet browser from a computer or WiFi device that is connected to the
network.
2. T
ype http://www
.routerlogin.net.
A login screen displays.
3. Enter the user name and password for the modem router.
The user name is admin.
The default password is
password. The user name and
password are case-sensitive.
4. Click the OK button.
The BASIC Home screen displays.
5. Select ADVANCED > Setup > VLAN/Bridge Settings
.
The VLAN/Bridge Settings screen displays.
6. Select the Enable VLAN/Bridge Group check box.
The screen expands.
7. Select the By bridge group radio button.
To Next Page
