Supplemental Information
291
AC1600 WiFi VDSL/ADSL Modem Router Model D6400
Technical Specifications
Table 6. D6400 modem router specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP,
and SMB
Power adapter • North
America: 120V, 60 Hz, input
• UK, Australia: 240V
, 50 Hz, input
• Europe: 230V, 50 Hz, input
• All regions: 12V @ 2.5 A output
Dimensions Dimensions: 191 mm x 198.5 mm x 65 mm (7.5 in. x 7.8 in. x 2.6 in.)
W
eight Weight: 422 g (0.93 lb)
Operating temperature 0° to 40°C (32º to 104ºF)
Operating humidity 90% maximum relative humidity, noncondensing
Electromagnetic emissions • EN 55022:2010/AC:201
1, Class B
• CISPR 22:2008, Class B
• AS/NZS CISPR 22:2009/Amdt 1:2010, Class B
LAN Four RJ-45 LAN ports supporting 10BASE-T
, 100BASE-TX, and 1000BASE-T
WAN One RJ-45 Internet port supporting 10BASE-T, 100BASE-TX, and 1000BASE-T
DSL One RJ-11 DSL port for ADSL or VDSL service
WiFi Maximum WiFi signal rate complies with the IEEE 802.11 standard. See the
footnote for the table in Factory Settings on page 289.
Radio data rates Auto-rate sensing
Data encoding standards • IEEE 802.1
1ac 2.0
• IEEE 802.11n version 2.0
• IEEE 802.11n 256QAM IEEE 802.1
1g, IEEE 802.11b 2.4 GHz
IEEE 802.11n, IEEE 802.11a 5.0 GHz
Maximum computers per
WiFi network
Limited by the amount of WiFi network traffic generated by each node (typically
50–70 nodes).
