NETGEAR GC110 User Manual

Configure Switching
121
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
The Global Settings page displays.
6. Configure the following options:
• Spanning Tree State. Enable or disable the spanning tree operation on the switch.
• STP Operation Mode. Specify the STP version for the switch. The options are STP,
RSTP, and MSTP.
For more information, see Spanning Tree Protocol Overview on page 120.
• Configuration Name. Specify an identifier used to identify the configuration currently
being used.
The name can be up to 32 alphanumeric characters.
• Configuration Revision Level. Specify an identifier used to identify the configuration
currently being used.
The values allowed are between 0 and 65535. The default value is 0.
• Forward BPDU while STP Disabled. Enable or disable the BPDU Flood.
The BPDU flood option specifies whether spanning tree BPDUs are forwarded while
spanning tree is disabled on the switch.
7. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable STP Status fields displayed on the page.
Table 30. STP configuration status
Field Description
Configuration Digest Key Identifier used to identify the configuration currently being used.
STP Status
Bridge Identifier The bridge identifier for the CST. It is made up using the bridge priority and
the base MAC address of the bridge.
Time Since Topology Change The time in day-hour-minute-second format since the topology of the CST
last changed.
Topology Change Count The number of times that the topology changed for the CST.
Topology Change The value of the topology change parameter for the switch indicating
whether a topology change is in progress on any port assigned to the CST.
Possible values are True and False.
Designated Root The bridge identifier of the root bridge. It is made up from the bridge priority
and the base MAC address of the bridge.
Root Path Cost Path cost to the designated root for the CST.
Root Port Port to access the designated root for the CST.
Max Age (secs) The maximum age timer controls the maximum length of time in seconds
that passes before a bridge port saves its configuration BPDU information.
