Table 1. LEDs on switch
DescriptionLED
• Solid green .The device is powered on.
• Solid amber.The device is booting.
• Off. Power is not supplied to the device.
Power LED
• Solid amber.The fans has failed.
• Off.The fan is operating normally.
Fan LED (GS510TPP
only)
Upper LED Row (RJ-45 SPD state)
• Off: No link is established.
• Solid green: A valid 1000 Mbps link is established.
• Blinking green.The port is transmitting or receiving packets at 1000 Mbps.
• Solid amber. A valid 10/100 Mbps link is established.
• Blinking amber.The port is transmitting or receiving packets at 10/100 Mbps.
RJ-45 SPD Mode LED
(Link, Speed, Activity) for
copper ports 1 to 8
Lower LED Row (PoE state)
• Off: PoE mode is off.
• Solid green: PoE mode is on.
• Solid amber: A PoE fault occurred.
• Off: No SFP module link is established.
• Solid green. A valid 1000Mbps link is established.
• Blinking green.The SFP fiber port is transmitting or receiving packets at
1000 Mbps.
Link/ACT Mode LED for
SFP fiber ports
• Off. More than 7W of PoE power is available.
• Solid amber. Less than 7W of PoE power is available.
• Blinking amber. At least once during the previous two minutes, less than
7W of PoE power was available.
PoE Max LED
Switch Hardware Interfaces
The following sections describe the hardware interfaces on the switch.
Hardware Overview
12
ProSAFE 8-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports
