3. Check cable routing to make sure that cables are not damaged or creating a safety hazard
4. Ensure that all equipment is mounted properly and securely.
Optional Step 6: Install SFP Transceiver Modules
The following optional procedure describes how to install an optional SFP transceiver module into one of
the SFP ports of the switch.
Contact your NETGEAR sales office to purchase these modules. If you do not want
to install an SFP module, skip this procedure.
Note
To install an SFP transceiver module:
1. Insert the transceiver into the SFP port.
2. Press firmly on the flange of the module to seat it securely into the connector.
Step 7: Connect Devices to the Switch
The following procedure describes how to connect computers to the switch’s RJ-45 ports.The switch supports
Auto Uplink technology, which allows you to attach devices using either straight-through or crossover cables.
Ethernet specifications limit the cable length between the switch and the attached
device to 328 feet (100 meters).
Note
Installation
19
ProSAFE 8-Port Gigabit Smart Managed Switch with PoE+ and 2 SFP Ports
