GS700TS Smart Switch Software Administration Manual
Introduction to the Web Browser Interface 2-8
v1.0, June 2009
Deleting an Entry
To delete entries from a table:
1. Select the entries to be deleted.
2. Click DELETE to update the device.
Special Table Options
The NETGEAR web browser interface tables have a unique GUI design which includes the
following options:
• Gold Buttons
•Quick Boxes
• Interface View and Selection
Gold Buttons
Gold Buttons provide flexibility in viewing and configuring VLANs/LAGs on a port level. The
following example displays gold button basic usage options.
To view the LAG configuration of the ports of Unit 1:
1. Click anywhere on the Unit 1 ports gold button. The Unit 1 ports panel is displayed:
2. Select the Unit 1 ports to be added as LAG members within the selected LAG by clicking on
their respective boxes.
3. Click APPLY to update the device.
Figure 2-10
