Hardware descriptions of the 24-port PoE+
and PoE++ models
This section describes the switch hardware features for the following 8-port PoE+ and
PoE++ models:
•
Model M4250-26G4F-PoE+ (SKU GSM4230P)
-
24 PoE+ (802.3at) 1GBASE-T RJ-45 ports with a total PoE budget of 300W to be
shared among all ports
- Two 1GBASE-T RJ-45 ports
-
Four 1G SFP fiber uplink ports
•
Model M4250-26G4XF-PoE+ (SKU GSM4230PX)
-
24 PoE+ (802.3at) 1GBASE-T RJ-45 ports with a total PoE budget of 480W to be
shared among all ports
- Two 1GBASE-T RJ-45 ports
-
Four 10G SFP+ fiber uplink ports
•
Model M4250-26G4F-PoE++ (SKU GSM4230UP)
-
24 PoE++ (802.3bt) 1GBASE-T RJ-45 ports with a total PoE budget of 1440W
(with both internal power supply units connected) to be shared among all ports
- Two 1GBASE-T RJ-45 ports
-
Four 10G SFP+ fiber uplink ports
Front panel of the 24-port PoE+ and PoE++ models
The following figures illustrate the front panels of the 24-port PoE+ and PoE++ models,
the M4250-26G4F-PoE+, M4250-26G4XF-PoE+, and M4250-26G4F-PoE++.
Figure 7. Front panel model M4250-26G4F-PoE+
Hardware Installation Guide18Hardware Overview
AV Line of Fully Managed Switches M4250 Series
