S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Manage Device Security User Manual266
The previous figure shows a sample for models GS324T and GS324TP.
For information about the ACL Wizard, see
Use the ACL Wizard to Create a Simple ACL on
page 261.
Configure a Basic MAC ACL
A MAC ACL consists of a set of rules that are matched sequentially against a packet. When a
packet meets the match criteria of a rule, the specified rule action (Permit or Deny) is taken,
and the additional rules are not checked for a match.
Multiple steps are involved in defining a MAC ACL and applying it to the switch:
1. Create a MAC ACL ID (see Add a MAC ACL on page 266).
2. Create a MAC rule (see
Configure MAC ACL Rules on page 268).
3. Associate the MAC ACL with one or more interfaces (see
Configure MAC Bindings on
page 272).
You can view or delete MAC ACL configurations in the MAC Binding table (see
View or
Delete MAC ACL Bindings in the MAC Binding Table on page 274.
Add a MAC ACL
To add a MAC ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
