S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Manage Device Security User Manual277
6. In the IP ACL ID field, specify the ACL ID or IP ACL name, which depends on the IP ACL
type. The IP ACL ID is an integer in the following range:
• 1–99. Creates a basic IP
ACL, which allows you to permit or deny traf
fic from a
source IP address.
• 100–199. Creates an extended IP ACL, which allows you to permit or deny specific
types of Layer 3 or Layer 4 traf
fic from a source IP address to a destination IP
address. This type of ACL provides more granularity and filtering capabilities than the
standard IP ACL.
• IP ACL Name. Create an extended IP
ACL with a name string that is up to
31 alphanumeric characters in length.
The name must start with an alphabetic
character.
Each configured
ACL displays the following information:
• Rules. The number of rules currently configured for the IP ACL.
•
Type. Identifies the ACL as a basic IP
ACL (with ID from 1 to 99), extended IP ACL
(with ID from 100 to 199 or a name).
7. Click the Add button.
The IP ACL is added.
Change the Name of an IP ACL
To change the name of an IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Security >
ACL >
Advanced > IP ACL.
The IP ACL Configuration page displays.
6. Select the check box that is associated with the IP ACL.
7. In the
IP ACL field, specify the new name.
8. Click the Apply button.
Your settings are saved.
