S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Monitor the System User Manual307
• To clear the counters for multiple ports, select the check boxes associated with the
ports, and click the Clear button.
• To clear all counters for all ports, select the check box in the row heading, and click
the Clear
button.
The following table describes the EAP statistics displayed on the page.
Table 68. EAP statistics
Field Description
Port The port number.
EAPOL Frames Received The number of valid EAPoL frames of any type that were received by this
authenticator.
EAPOL Frames T
ransmitted The number of EAPoL frames of any type that were transmitted by this
authenticator.
EAPOL Start Frames
Received
The number of EAPoL start frames that were received by this authenticator.
EAPOL Logof
f Frames
Received
The number of EAPoL logoff frames that were received by this authenticator.
EAPOL Last Frame Version The protocol version number carried in the most recently received EAPoL frame.
EAPOL Last Frame Source The source MAC address carried in the most recently received EAPoL frame.
EAPOL Invalid Frames
Received
The number of EAPoL frames that were received by this authenticator in which
the frame type is not recognized.
EAPOL Length Error Frames
Received
The number of EAPoL frames that were received by this authenticator in which
the frame type is not recognized.
EAP Response/ID Frames
Received
The number of EAP response/identity frames that were received by this
authenticator
.
EAP Response Frames
Received
The number of valid EAP response frames (other than resp/ID frames) that were
received by this authenticator.
EAP Request/ID Frames
Transmitted
The number of EAP request/identity frames that were transmitted by this
authenticator.
EAP Request Frames
Transmitted
The number of EAP request frames (other than request/identity frames) that
were transmitted by this authenticator.
