Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
3-4 Installing the XE102 and the WGX102
September 2004 202-10042-01
b. Plug the XE102 into an electrical outlet near the router.
Figure 3-3: XE102 connected to a LAN port on your router
c. Shut down and restart your wireless computer.
2. PLUG THE WGX102 INTO A WALL OUTLET
a. Plug the WGX102 into an electrical outlet near the wireless computer that you want to
connect, and wait one minute. All three LEDs on the WGX102 will light up.
LAN
Ports
Power Internet
Router
Wall-Plugged Ethernet
Bridge XE102
To Next Page
