V iew Circuits - [2.1]
Each detection circuit may be viewed to ascertain its status. The circuit status conditions are:
Healthy (H)
-
The normal status of an alarm circuit.
Active (A)
-
The status of an activated alarm circuit .
Tamper (T)
-
The status of a tampered circuit (open circuit).
Shorted (S)
-
status of circuit which is shorted. A shorted status is generated when a
normally open device such as pressure pad or Exit Terminator is
activated.
1. Ensure that “User menu 2" is selected.
Press 1 to select the View Circuits option.
The display will show:
2. Select the circuit by entering its number
or by pressing:
A To move up one circuit
B To move up ten circuits
C To move down one circuit
e.g., to view circuit 10, enter “10", the
top line of the display shows the circuit
text (if programmed) and the bottom
line shows the status of the circuit e.g.:
3. Press] toleavethisoptionandreturnto
“User menu 2".
Set Clock - [2.2]
The system clock uses the 24hr format and provides event times for the system log as well as
displaying the current time when the system is set or unset. The clock is set as follows:
1. Ensure that “User menu 2" is selected.
Press 2 to select the Set Clock option. The
display will show:
2. Enter the time using the number keys,
e.g., enter “1700" for 5.00 PM. The display
will show:
3. Press [ to update with new time setting
or press ] abandon this option and return
to “User menu 2".
24
User Menu 2 TS790 & TS90 0 User Manual
Front Door
CCT 10 Healthy
CCT 10-H
10-H
View Circuits
Enter CCT No.>--
LCD
CCT 01-H
Starburst
01-H
LED
Set Clock > ----
LCD
-- --
Starburst
----
LED
Set Clock > 1700
1700
1700
