Networker TS900 - Time Switch Programming

Time Switch A, B & C - [ 3.1]
The TS790/TS900 system has three programmable Time Switch outputs A, B and C. Each output
can be independently set with up to three separate on/off times and made to operate on
various days of the week.These outputs may be used to control internalor external lighting via a
relay.
When this menu option is selected the keys function as follows:
1 First ON time 2 Second ON time 3 Third ON time
4 First OFF time 5 Second OFF time 6 Third OFF time
7 Days of operation (1st) 8 Days of operation (2nd) 9 Days of operation (3rd)
[ Set day 0 Toggle output ON/OFF ] Escape
A Select Time Switch A B Select Time Switch B C Select Time Switch C
Selecting Time Switches
When the “Time Switch” option is selected “Time Switch A” is automatically selected, to select
one of the other “Time Switches” proceed as follows:
1. Ensure that “User menu 3" is selected.
Press 1 to select the Time Swi tch option.
The display will show:
2. Select the Time Switch by pressing:
A for “Time Switch A”
B for “Time Switch B”
C for “Time Switch C”
e.g., to select “Time Switch B” press
“B”. The display will show the selected
Time Switch, e.g.:
Setting The O n Times
To set the first, second and third “ON” times proceed as follows:
1. Select the 1st, 2nd or 3rd “ON” time,
e.g., to select the 1st ON time press “1". The
display will show:
2. Enter the “ON” time in a 24Hr format,
e.g., enter 1700 for 5.00 PM. The display will
show:
3. Press [ to accept the time setting. The
display will show:
4. Repeat steps 2 and 3 for the second
and third “ON” times as required.
36
User Menu 3 TS790 & TS90 0 User Manual
Time Switch A
Select Option :-
LCD
TIMER.A-
Starburst
TS
.
A-
LED
Time Switch B
Select Option :-
TIMER.B-
TS
.
B-
Time Switch B
On-time 1 0000
LCD
0000
Starburst
0000
LED
Time Switch B
On-time 1 1700
1700
1700
Time Switch B
Select Option :-
TIMER.B-
TS
.
B-
