New Focus Vortex 6000 Series - Using the Safety Interlock

6000 Vortex Series User Safety • 7
Figure 2:
Labels on the back
of the laser head
Using the Safety Interlock
The safety interlock connector on the back of the Vortex controller is
provided for external safety systems. The system is shipped with a
jumper across the interlock terminals. Do not remove this jumper
unless you are using the safety interlock feature; the laser will not emit
light unless the interlock circuit is closed. The circuit carries 15-V DC.
Back of laser head Danger labels
