Technical Parameters
Specification
Parameter
Backlight Type LED
Aspect Ratio 16 : 9
Physical Resolution 3840 x 2160 Pixel (4K) / 1920 x 1080 (2K)
Viewing Angle 178°
Display Colors 10bit
LCD Brightness 370cd/m²
Contrast Ratio (Typical) 4000 : 1
Response Time (Typical) 8ms
Viewing Angle 178°
Life Time (working hours) 30,000 hours
Power Consumption
65, 70 inch: Maximum < 220W
75 inch: < 350W
80, 86 inch: < 450W
Standby Mode: ≤ 0.5W
Working Voltage AC 100V - 240V, 50Hz/60Hz
Input Current
65, 70 inch: Max 2.5A
75 inch: Max 4.0A
80, 86 inch: Max 4.5A
Touch Screen Material Tempered glass
Touch Surface Technology Anti-Glare glass (optional)
Transparency > 90%
Sensing Method Infrared Touch
Touch Point 10 Points in Windows/ 5 Points in Android
Writing Method Finger or pen
Cursor Speed 100Point/s
Positioning Accuracy 5mm
Communication Interface USB-B
Front Interface Input Ports
Microphone (3.5mm) x 1, USB (Touch) x 1,
USB (OPS) x 2, HDMI x 1, Display Port x 1,
USB (Android) x 1
