Installation Requirements
Mounting
Ventilation
You can choose the mounting method that best fits your needs.
If you choose to mount on a mobile stand, use the mounting rack for support. The
weight capacity of the mounting rack should be at last four times the display weight.
The weight capacity of the mounting support must be four times the actual weight of
the display to ensure the interactive display remains steady.
When you to mount the display on a wall, the weight capacity of the mounting
surface must be at least four times of the weight of the display. When the mounting
surface is a wall or ceiling of a building, the wall must be built with solid bricks,
concrete, or materials of equal intensity. If you need to mount the display on a looser
surface, such as a wall with a thick layer of wallpaper, take necessary measures to
ensure that the display is steadily mounted.
Ventilation requirements
Distance to the surface for installation (in)
Nominal power Left and right sides Top Bottom Back
Greater than 100 W
3.93 7.87 7.87 3.93
WARNING
If the product is
mounted inside a wall or a cabinet, in addition to the preceding
requirements, the area around the ventilation holes at the bottom, top, and two
s
ides must be at least 50% of the sealing surface to ensure proper ventilation.
