About The Meter
2.4 FRONT OF THE METER
Figure 2-1 shows each part of the front of the three-color programmable
“Big” LED display meter (Version B).
Figure 5-1. Front-Panel with Big Display
Figure 2-2 shows each part of the front of the standard LED display meter.
Figure 5-2. Front-Panel wtih Standard Display
These meter display windows (both versions) light when appropriate:
1- Setpoint 1 status
2 - Setpoint 2 status
C - °C unit indicator
F - °F unit indicator
5 Pushbuttons for programming the meter.
//
䊱䊳
••••
12
RESETMENU
DEVMAXSETPTS
C
F
2
Digital LED Display:
- 1.9.9.9 or 9.9.9.9 4-digit
three color programmable,
21 mm (0.83") high LED
display with programmable
decimal point.
Digital LED Display:
- 1.9.9.9. or 9.9.9.9.
14 segment, 13.8 mm
(0.54") high LED display
with programmable
decimal point.
