SECTION 9. FACTORY PRESET VALUES
Table 9-1. Factory Preset Values
42
MENU ITEM FACTORY PRESET VALUES
INPT Input Type: RTD.3
DEC.P Decimal Point Position: FFFF
RD.CF Reading Configuration:
R.1=F (Fahrenheit)
COLR Normal Color Display:
REd or GRN (Note: Depending how it was ordered)
S1.CF Setpoint 1 Configuration:
S.1=A (Setpoint is active above)
S.2=U (Setpoint is unlatched)
S2.CF Setpoint 2 Configuration:
S.1=A (Setpoint is active above)
S.2=U (Setpoint is unlatched)
S1.DB Setpoint 1 Deadband: 0003
S2.DB Setpoint 2 Deadband: 0003
OT.CF Output Configuration:
O.1=E (Analog output is enabled)
O.2=C (Analog output is current)
O.3=A (Analog output follows the display value)
OT.S.O Output Scale and Offset:
0-1000 = 4-20 mA dc
LK.CF Lock Out Configuration
RS=E (Enable the RESET button in the run mode)
SP=E (Enable setpoint changes)
L3=0 (SETPTS button display setpoint values)
bRit M.brt (Brightness Level)
SP1 Setpoint 1 Value: 0000
SP2 Setpoint 2 Value: 0000
