Getting Started
3.2 MAIN BOARD POWER JUMPERS (Continued)
Figure 3-2 shows the main board jumpers.
Figure 3-2. Main Board Jumper Positions (6 S2 Pins)
Figure 3-3. Upper Option Board Installation
P1
TB5
Attach cable
to P1.
