Getting Started
3.5 CONNECTING MAIN POWER (Continued)
Connect the dc main power connections as shown in Figure 3-10.
Figure 3-10. Main Power Connections - DC Powered Unit
3.6 ANALOG AND RELAY OUTPUT CONNECTIONS
If you have purchased a meter with analog or dual relay or isolated analog output, refer to the
following figures for output connections.
Figure 3-11. Analog Output Connections
