Configuring The Meter
4.13 RTD TEMPERATURE OFFSET (T.OFF)
A new item has been added to calibrate for any offset error due to the RTD. This item will enable
you to compensate any temperature offset due to the RTD transducer:
OFFSET = ACTUAL TEMPERATURE - DISPLAY TEMPERATURE
1. Press the MENU button until "T.OFF" displays.
2. Press the
䊳
/DEV button. Previous offset value with digit 4 flashing will be displayed.
3. Press the
䊳
/DEV button again. Reading temperature will be displayed (with no digit
flashing).
4. a. If the value is okay, then press the MENU button. Display will show "STRD" and 0
value will be entered at the offset.
b. If the value is not okay, then enter the actual temperature using the
䊳
/DEV and the
䊱
/MAX buttons.
5. Press the MENU button to store the changes.
a. Temperature unit is either celsius or fahrenheit and will always be displayed at
0.1 degree resolution. The meter flashes corresponding LED.
b. MAX/MIN offset value will be ±25.0°C or 45.0°F. If offset the limit, the meter will
flash "ER 3" and previous offset will not be changed.
4
Note
☞
