Modem Reference Manual for EL470 IP Satellite Modem
Command
MoBufCont
Buffer contents Buffer contents
Values GUI Unit
%
Cmd Unit Factory Default (CU)
% 49
Expert Range (CU)
0 .. 100
Command
MoBufSize
Input buffer size Input buffer size
Location /Modem/Monitor/Modulation
Description
Readout of the physical size of the FIFO buffer between the interface and
the modulator part.
RMCP
Command
ibs Access Normal user :
no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoBufSize
OID 1.3.6.1.4.1.5835.3.1.3.1.6.1.1
Values GUI Unit
bytes
Cmd Unit Factory Default (CU)
bytes 2048
Expert Range (CU)
0 .. 16384
Command
MoOutLevelDet
Modulator output level
measurement
Output level msmt.
Location /Modem/Monitor/Modulation
Description
Readout of the modulator measured output level which is expressed in
dBm and measured with a resolution of 0.1 dBm.
RMCP
Command
old Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoOutLevelDet
OID 1.3.6.1.4.1.5835.3.1.3.1.75.1.1
Values GUI Unit
dBm
Cmd Unit Factory Default (CU)
dBm -15
Expert Range (CU)
-50 .. -10
Command
MoTxOffs
Transmit clock offset Tx clock offset
Location /Modem/Monitor/Modulation
Description
Readout of the transmit clock offset. This is the offset (in ppm) between
the configured symbol rate and the actual symbol rate when the device
operates with external transmit clock. This offset indication is not
applicable if the internal transmit clock is selected or if the transmit clock is
not synchronised to the interface clock.
RMCP
Command
Trd Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
version 3.1
