Modem Reference Manual for EL470 IP Satellite Modem
Command
MoTxOffs
Transmit clock offset Tx clock offset
Command ntcDevsMod01MoTxOffs
OID 1.3.6.1.4.1.5835.3.1.3.1.36.1.1
Values GUI Unit
ppm
Cmd Unit Factory Default (CU)
ppm 0
Expert Range (CU)
-500 .. 500
Command
MoPhaseErrDev
Modulator clock phase
error deviation
Phase error deviation
Location /Modem/Monitor/Modulation
Description
Readout of the modulator clock phase error deviation expressed in
nanosecond. The clock phase error deviation is the average value of
rectified phase error.
RMCP
Command
ped Access Normal user :
no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoPhaseErrDev
OID 1.3.6.1.4.1.5835.3.1.3.1.80.1.1
Values GUI Unit
ns
Cmd Unit Factory Default (CU)
ns 0
Expert Range (CU)
0 .. 4294967295
Command
MoDelaySetp
Delay setpoint Delay setpoint
Location /Modem/Monitor/Modulation
Only valid for mode ASI (TS) <-> Air (TS) (fixed delay).
Description
Readout of the active delay set-point expressed in nanoseconds.
When the modulator is operating with external transmit clock, the transmit
clock is slaved to the incoming data frames via a PLL circuit. This variable
presents the current operating point (set-point) of the PLL.
RMCP
Command
mds Access Normal user :
no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoDelaySetp
OID 1.3.6.1.4.1.5835.3.1.3.1.65.1.1
Values GUI Unit
ns
Cmd Unit Factory Default (CU)
ns 0
Expert Range (CU)
0 .. 4294967295
version 3.1
149
