Modem Reference Manual for EL470 IP Satellite Modem
Command
MoClkLoopState
clock loop state clock loop state
Location /Modem/Monitor/Modulation
Description
Readout of the state of the clock tracking loop on the modulator board.
RMCP
Command
Cls Access Normal user : no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoClkLoopState
OID 1.3.6.1.4.1.5835.3.1.3.1.61.1.1
Values Factory Default
dump
Enumeration Value
Dump
Acq
Lock
Hold
0
1
2
3
Command
MoMainState
main acquisition state main acquisition state
Location /Modem/Monitor/Modulation
Description
Readout of the modulator current main acquisition state.
RMCP
Command
mas Access Normal user : no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoMainState
OID 1.3.6.1.4.1.5835.3.1.3.1.74.1.1
Values Factory Default
setup
Enumeration Value
Setup
Unsync
FramSync
TbSync
FullSync
InputSync
BbSync
PlSync
0
1
2
3
4
5
6
7
Command
MoGainCtrlState
Gain control state Gain control state
Location /Modem/Monitor/Modulation
Description
Readout of the modulator output level (gain) control state. When gain
control is set to automatic gain control and the gain loop is settling, the
display will indicate settling. In this short time the output level will approach
the requested level.
RMCP
Command
GcS Access Normal user : no access
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
version 3.1
