Modem
Reference Manual for EL470 IP Satellite Modem
Command
MoDummyPLCnt
Dummy Physical Layer
frame-count
Dummy PL count
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 0
Expert Range (CU)
0 .. 4294967295
Command
MoPLEfficiency
Physical layer
efficiency
PL efficiency
Location /Modem/Monitor/Modulation/Frames
Description
Readout of the physical layer efficiency of the DVB-S2 modulator. The
physical layer efficiency is expressed in % and is calculated as the ratio
between dummy physical layer frame symbol rate and available symbol
rate. It is 100 % when no dummy physical layer frames are inserted.
RMCP
Command
ple Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoPLEfficiency
OID 1.3.6.1.4.1.5835.3.1.3.1.76.1.1
Values GUI Unit
%
Cmd Unit Factory Default (CU)
% 0
Expert Range (CU)
0 .. 100
Command
MoBBLEfficiency
Baseband layer
efficiency
BBL efficiency
Location /Modem/Monitor/Modulation/Frames
Description
Readout of the baseband layer efficiency of the DVB-S2 modulator. The
baseband layer efficiency is expressed in % and is calculated as the ratio
between used payload bytes and available payload bytes within the
baseband frames. In other words, it represents the filling level of the DVB-
S2 baseband frames.
RMCP
Command
ble Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoBBLEfficiency
OID 1.3.6.1.4.1.5835.3.1.3.1.56.1.1
Values GUI Unit
%
Cmd Unit Factory Default (CU)
% 0
Expert Range (CU)
0 .. 100
Command
MoBBShortFrameRatio
Short frames Short frames
Location /Modem/Monitor/Modulation/Frames
Description
Readout of the ratio of short-frames in the DVB-S2 modulator. It is
expressed in % and is calculated as the ratio of short-frames over the total
(optionally filtered) baseband frames.
RMCP
Command
sfr Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01ModulatorEntry
version 3.1
154
