Modem Reference Manual for EL470 IP Satellite Modem
Command
IfChConfigEthRxPID
OUT PID OUT PID
Used as
variable of
Command(s)
IfChConfigEthRx
Page
58
Description
Configuration of the PID of the outgoing MPEG transport stream on which
the incoming Ethernet packets in a channel configuration are transmitted.
RMCP
Command
IRP Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfChConfigEthRxPID
OID 1.3.6.1.4.1.5835.3.1.4.1.63.1.1
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 0
Expert Range (CU)
0 .. 8192
Command
IfChConfigEthRxAirMac
OUT Air-MAC address OUT Air-MAC address
Used as
variable of
Command(s)
IfChConfigEthRx
Page
58
Description
Configuration of the air-MAC address if the encapsulator has enabled air
MAC destination addressing.
RMCP
Command
IRA Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfChConfigEthRxAirMac
OID 1.3.6.1.4.1.5835.3.1.4.1.60.1.1
Values Factory Default
00:00:00:00:00:00
String Description
length : 17 (fixed)
format : ^([\da-fA-F]{2}:){5}[\da-fA-F]{2}$
Command
IfChConfigEthRxPacking
Delay
Packing delay Packing delay
Used as
variable of
Command(s)
IfChConfigEthRx
Page
58
Description
Configuration of the maximum delay allowed during the packing process of
a DVB-S2 baseband frame or a transport stream cell.
RMCP
Command
bsd Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfChConfigEthRxPackingDelay
OID 1.3.6.1.4.1.5835.3.1.4.1.119.1.1
Values GUI Unit Cmd Unit Factory Default (CU) Expert Range (CU)
version 3.1
178
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
