/Modem/Control/Interfaces/Ethernet/IP encap-decap/Ethernet Rx routes
Structured Command
IfChConfigEthRx
Ethernet receive
routes
Ethernet Rx routes
Location /Modem/Control/Interfaces/Ethernet/ipencap/Ethernet Rx routes
Description
Configuration of the routes from the Ethernet interface towards the
satellite interface. Packets are captured from the specified VLAN and
filtered by the Ethernet MAC address and/or IP address. The matching
packets are encapsulated by the specified protocol engine using the
specified PID and air-MAC address (if needed by protocol settings).
Remark1: Ethernet MAC address = 00:00:00:00:00:00 matches all
addresses.
Remark2: IP address = 0.0.0.0 matches all addresses.
RMCP
Command
ICR
array : [1 .. 255]
Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfChConfigEthRx
OID 1.3.6.1.4.1.5835.3.1.4.1.59.1.1.[1 .. 255]
Variables
IfChConfigEthRxEnable
IfChConfigEthRxVlanId
IfChConfigEthRxMac
IfChConfigEthRxIp
IfChConfigEthRxIpMask
IfChConfigEthRxStreamId
IfChConfigEthRxPID
IfChConfigEthRxAirMac
IfChConfigEthRxPackingDelay
Page
175
176
176
176
177
177
178
178
178
/Modem/Control/Interfaces/Ethernet/IP encap-decap/Demod Rx routes
Structured Command
IfChConfigEthTx
Demod Rx routes Demod Rx routes
Location /Modem/Control/Interfaces/Ethernet/ipencap/Demod Rx routes
Description
Configuration of the routing from the demodulator interface towards the
Ethernet network. MPEG transport stream packets with the specified PID
are decoded by the protocol engine. If the protocol requires an Air-MAC
address, the specified Air-MAC address is used and the resulting Ethernet
packet is sent to the specified VLAN. If an Ethernet MAC address is
specified (00:00:00:00:00:00 means "not set"), the destination MAC
address of the Ethernet frame is set accordingly. If the Ethernet MAC
address is not specified, the destination MAC address for the next HOP
will be found by using ARP.
RMCP
Command
ICT
array : [1 .. 32]
Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfChConfigEthTx
OID 1.3.6.1.4.1.5835.3.1.4.1.67.1.1.[1 .. 32]
Variables Page
