Unit Menu
Reference Manual for EL470 IP Satellite Modem
The device reset is not displayed in the tree view of the Graphical
user interface (GUI). This function is located in the Function
controls window of the GUI under the tab Reset Device.
We refer to the explanation of the GUI in the user manual of this
device.
Command
SyDevRst
Device reset Device reset
Location /Unit/Control
Description
Command to initiate a device reset.
• A soft reset will send the reset command to all boards.
• A config reset will clear all operational control settings and place
them back on default value.
• A hard reset will power-cycle the device. After a reset, the device
initially starts up the boot loader code, waits for 2 seconds and then
activates the application code. Consequently, the unit performs a
number of initialisation routines, loads its default configuration from
permanent memory and performs a self test.
• The selection upgrade is used whenever an upgrade through
bucket-files is performed; refer to the appendices for details on the
upgrade procedure.
• A factory reset clears all device settings (including Ethernet
settings) and place them back on default value. You can only reach
this reset option from the device front panel.
• The selection reset upgrade logs is used to delete a bucket
upgrade log. When an upgrade fails, the failure will be written in the
upgrade_log.html report which will be used by the unit to generate a
general device alarm. When this happens the unit should be
upgraded again to reset this flag, although it could be desired to
reset this flag without doing any upgrade. Therefore this selection
will only clear the upgrade_log.html file.
RMCP
Command
SRr Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyDevRst
OID 1.3.6.1.4.1.5835.3.1.1.1.28.0.1
Values Factory Default
none
Enumeration Value
None
Soft
Configs
Hard
Upgrade
Factory
Upgrade logs
0
1
2
4
6
7
8
version 3.1
21
