Unit Menu Reference Manual for EL470 IP Satellite Modem
Command
ExtLOFreq
Ext LO Freq. out Ext LO Freq. out
Location /Unit/Control
Description
Configuration of the local oscillator frequency for a non-Newtec external
up- or down-converter. This allows the operator to enter the RF frequency
directly without having to re-calculate the frequency to L-band or IF. Use
the external spectral inversion menu to indicate if local oscillator frequency
is above or below the RF frequency.
RMCP
Command
LOF Access Normal user : no
access
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01ExtLOFreq
OID 1.3.6.1.4.1.5835.3.1.3.1.26.1.1
Values GUI Unit
MHz
Cmd Unit Factory Default (CU)
Hz 12450
Expert Range (CU)
0 .. 99000000000
Command
DmExtLOFreq
LO IFL in LO IFL in
Location /Unit/Control
Description
Configuration of the local oscillator frequency of a converter in case a non-
Newtec external up- or down-converter is used. This allows the operator to
enter the radio frequency directly without having to recalculate the
frequency to L-band or IF-band. Use the external spectral inversion menu
to indicate if the local oscillator frequency is above or below the radio
frequency.
RMCP
Command
LOf
array : [1 .. 2]
Access Normal user :
no access
Expert user : RW
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmExtLOFreq
OID 1.3.6.1.4.1.5835.3.1.13.1.43.1.1.[1 .. 2]
Values GUI Unit
MHz
Cmd Unit Factory Default (CU)
Hz 12450
Expert Range (CU)
0 .. 99000000000
Command
DmExtLOPolVal
Spectrum inv. IFL in Spect. inv. IFL i
Location /Unit/Control
Description
Configuration of the external converter spectrum polarity:
• When the spectrum is direct, the formula is:
f(RF) = f(LO) + f(L-band).
• When the spectrum is inverted, the formula is:
f(RF) = f(LO) ? f(L-band).Remark: Use inverted spectrum whenever
the local oscillator frequency is above the radio frequency.
RMCP
Command
LOp
array : [1 .. 2]
Access Normal user : no access
Expert user : RW
version 3.1
27
