Unit Menu Reference Manual for EL470 IP Satellite Modem
Command
DmExtLOPolVal
Spectrum inv. IFL in Spect. inv. IFL i
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmExtLOPolVal
OID 1.3.6.1.4.1.5835.3.1.13.1.44.1.1.[1 .. 2]
Values Factory Default
directSpectrum
Enumeration Value
Direct spectrum
Inverted spectrum
1
2
Command
ExtLOPolVal
Ext. spectrum inv. Ext. spectrum inv.
Location /Unit/Control
Description
Configuration of the external converter spectrum polarity:
• When the spectrum is direct, the formula is:
f(RF) = f(LO) + f(L-band).
• When the spectrum is inverted, the formula is:
f(RF) = f(LO) ? f(L-band).Remark: Use inverted spectrum whenever
the local oscillator frequency is above the radio frequency.
RMCP
Command
LOS Access Normal user : no access
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01ExtLOPolVal
OID 1.3.6.1.4.1.5835.3.1.3.1.39.1.1
Values Factory Default
directSpectrum
Enumeration Value
Direct spectrum
Inverted spectrum
1
2
/Unit/Control/ODU
Command
ODPow
Outdoor power supply Outdoor power supply
Location /Unit/Control/ODU
Description
Configuration command to enable or disable the outdoor power supply as
delivered by the outdoor unity and LNB controller unit.
RMCP
Command
ODp Access Normal user : no access
Expert user : RW
SNMP Table ntcDevsMod01ODUEntry
Command ntcDevsMod01ODPow
OID 1.3.6.1.4.1.5835.3.1.14.1.14.1.1
Values Factory Default
disabled
Enumeration Value
Disabled
Enabled
0
1
version 3.1
