Modem Reference Manual for EL470 IP Satellite Modem
Command
IfMPEGoUDPRXSettings
UDPPort
RX UDP port RX UDP port
Location /Modem/Control/Interfaces/Ethernet/IP termination/MPEG over IP
Description
Configuration of the UDP port number for MPEG over UDP decapsulation.
Remark: This setting applies to the reception of UDP packets.
RMCP
Command
VRp Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfMPEGoUDPRXSettingsUDPPort
OID 1.3.6.1.4.1.5835.3.1.4.1.150.1.1
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 9035
Expert Range (CU)
0 .. 65535
/Modem/Control/Interfaces/Ethernet/IP termination/S2BBF over IP
Only valid for Eth (S2BBFoE) processing mode.
Command
IfDvbs2BboeRxUdpPort
S2BBFoE rx UDP port S2BBFoE rx UDP port
Location /Modem/Control/Interfaces/Ethernet/IP termination/S2BBF over IP
Description
This field defines the UDP port used for receiving DVB-S2 baseband
frames over Ethernet from an external encapsulator (e.g.: EL860)
RMCP
Command
brU Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfDvbs2BboeRxUdpPort
OID 1.3.6.1.4.1.5835.3.1.4.1.134.1.1
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 12345
Expert Range (CU)
0 .. 65535
Command
IfDvbs2BboeTxIp
S2BBFoE tx IP
address
S2BBFoE tx IP addres
Location /Modem/Control/Interfaces/Ethernet/IP termination/S2BBF over IP
Description Configuration of the IP address to which DVB-S2 baseband frames will be
transmitted over the Ethernet interface. This address can be a unicast or
multicast IP address.
RMCP
Command
btI Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfDvbs2BboeTxIp
OID 1.3.6.1.4.1.5835.3.1.4.1.228.1.1
Values Factory Default String Description
version 3.1
67
