Modem Reference Manual for EL470 IP Satellite Modem
/Modem/Control/Interfaces/Ethernet/IP termination/ntS2BBF over IP
Only valid for Eth (ntS2BBFoE) processing mode.
Command
IfDvbs2BbRxUdpPort
ntS2BBFoE UDP port ntS2BBFoE UDP port
Location /Modem/Control/Interfaces/Ethernet/IP termination/ntS2BBF over IP
Description
This field defines the UDP port used for receiving DVB-S2 baseband
frames over Ethernet from an external encapsulator (e.g.: AZ810)
RMCP
Command
bru Access Normal user : no
access
Expert user : R
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfDvbs2BbRxUdpPort
OID 1.3.6.1.4.1.5835.3.1.4.1.130.1.1
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 12345
Expert Range (CU)
0 .. 65535
Command
IfDvbs2BboeTxIp
S2BBFoE tx IP
address
S2BBFoE tx IP addres
Location /Modem/Control/Interfaces/Ethernet/IP termination/ntS2BBF over IP
Description Configuration of the IP address to which DVB-S2 baseband frames will be
transmitted over the Ethernet interface. This address can be a unicast or
multicast IP address.
RMCP
Command
btI Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfDvbs2BboeTxIp
OID 1.3.6.1.4.1.5835.3.1.4.1.228.1.1
Values Factory Default
0.0.0.0
String Description
length : 0 .. 15
format : \d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}
version 3.1
69
