Modem Reference Manual for EL470 IP Satellite Modem
Command
MoSymRate
Symbol rate Symbol rate
Location /Modem/Control/Modulation/Main
Description
Configuration of the symbol rate. The actual range depends on installed
hardware and software capability.
RMCP
Command
TRs Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoSymRate
OID 1.3.6.1.4.1.5835.3.1.3.1.32.1.1
Values GUI Unit
Mbaud
Cmd Unit Factory Default (CU)
baud 6.000.000
Expert Range (CU)
50000 .. 68000000
Command
MoOpOutputFreq
Operational output
frequency
Output frequency
Location /Modem/Control/Modulation/Main
Description
Configuration of the operational output frequency in case of an active
L-band output.
RMCP
Command
OOF Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoOpOutputFreq
OID 1.3.6.1.4.1.5835.3.1.3.1.38.1.1
Values GUI Unit
MHz
Cmd Unit Factory Default (CU)
Hz 1.450.000.000
Expert Range (CU)
-1e+38 .. 1e+38
Command
MoOutputLevel
Output level Output level
Location /Modem/Control/Modulation/Main
Description
Read out of the output level in dBm. The actual range is determined by the
gain of the converter (which depends on operating frequency) and the
gain of an optional amplifier.
Remark: The displayed level can be affected by introducing a level offset
(see MoOLevelOffset).
RMCP
Command
OOL
array : [1 ..
2]
Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoOutputLevel
OID 1.3.6.1.4.1.5835.3.1.3.1.29.1.1.[1 .. 2]
Values GUI Unit
dBm
Cmd Unit Factory Default (CU)
dBm -15
Expert Range (CU)
-35 to +5
version 3.1
