Reference Manual for EL470 IP Satellite Modem
Command
MoAmplEq
Amplitude slope
equaliser
Slope equaliser
Location /Modem/Control/Modulation/PHY
Description
Configuration of the amplitude slope equaliser. An amplitude slope in the
up-converter or in the high power amplifier can be compensated by using
this equaliser which has a maximum range of ± 2 dB/50 MHz. This is done
by changing the corresponding control parameter in steps of one unit in
the range of ± 7 units.
RMCP
Command
TLe Access Normal user : no
access
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoAmplEq
OID 1.3.6.1.4.1.5835.3.1.3.1.3.1.1
Values GUI Unit
units
Cmd Unit Factory Default (CU)
units 0
Expert Range (CU)
-7 .. 7
Command
MoExcBw
Roll-off factor Roll-off factor
Location /Modem/Control/Modulation/PHY
Description
Configuration of the roll-off factor. The excess bandwidth defines the root
cosine roll-off factor for the matched filter at the modulator output.
Remark: A change of the excess bandwidth disables transmit.
RMCP
Command
TFr Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
Command ntcDevsMod01MoExcBw
OID 1.3.6.1.4.1.5835.3.1.3.1.9.1.1
Values Factory Default
x25RCRO
Enumeration Value
35%
25%
20%
1
2
3
Command
MoMonOutputMode
Monitoring output
mode
Monitor output mode
Location /Modem/Control/Modulation/PHY
Description
Configuration of the monitoring output functional mode.
• Always on: The monitor output signal is continuously active
irrespective of the operational output status.
• Follow Tx: The monitor output status follows the operational output
status. When transmit is off, the monitor output will also be disabled.
RMCP
Command
MOM Access Normal user : no access
Expert user : RW
SNMP Table ntcDevsMod01ModulatorEntry
version 3.1
91
