Chapter 2: Jumpers and Connectors
NDiB M535
The figure below is the top and bottom view of the NDiB M535 mainboard
which is the mainboard used in NDiS M535. It shows the locations of the
jumpers and connectors.
SW1
CN5
CN8 J4
CN6 CN7
LED1
J3
J2
CN3
CN2
CN1
Top View
Locations of the Jumpers and Connectors for NDiB M535
