Nexcom NDiS M535 - Installing Memory Modules

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
20
NDiS M535 User Manual
Chapter 3: System Setup
Installing a SO-DIMM Memory Module
1. At the bottom of the system, loosen the screws on the bottom cover and
on the side, then remove the cover from the chassis.
DIMM1 DIMM2
Screw
