NDiS M535 User Manual
Chapter 2: Jumpers and Connectors
Line-out Connector
Connector type: 3.5mm TRS
Connector location: CN10
Pin Definition Pin Definition
1 GND 2 GND
3 LINE2_OUT_R_FB 4 LINE2_OUT_L_FB
5 JD
