NDiS M535 User Manual
Chapter 2: Jumpers and Connectors
Jumpers
RTC Control Connector
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: J3
Pin Settings
1-2 On Normal
2-3 On Clear CMOS
1-2 On: default
Pin Definition
1 RTC_RST#_PU
2 RTC_RST#
3 CLR_CMOS
1 3
