Nexcom NDiS M535 - JAE-TX25 Connector

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
15
NDiS M535 User Manual
Chapter 2: Jumpers and Connectors
JAE-TX25 Connector
Connector location: CN1
Pin Definition Pin Definition
1 DDP_3N 18 TMDS_CLK+
2 DDP_3P 19 GND
3 GND 20 TMDS0-
4 DDP_2N 21 TMDS0+
5 DDP_2P 22 GND
6 GND 23 TMDS1-
7 DDP_1N 24 TMDS1+
8 DDP_1P 25 GND
9 GND 26 TMDS2-
10 DDP_0N 27 TMDS2+
11 DDP_0P 28 GND
12 GND 29 DVI_DDC_DATA
13 DDP_AUXN 30 DVI_DDC_CLK
14 DDP_AUXP 31 DVI_HPD
15 DDP_HPD 32 GND
16 GND 33 +12V~+19V
17 TMDS_CLK- 34 +12V~+19V
Pin Definition Pin Definition
35 +12V~+19V 58 StdA_SSTX+
36 +12V~+19V 59 GND
37 +12V~+19V 60 USB_DN2
38 +12V~+19V 61 USB_DP2
39 +12V~+19V 62 GND
40 +12V~+19V 63 USB_PN1
41 RSVD 64 USB_PP1
42 RSVD 65 GND
43 RSVD 66 USB_PN0
44 RSVD 67 USB_PP0
45 RSVD 68 GND
46 RSVD 69 AZ_LINEOUT_L
47 RSVD 70 AZ_LINEOUT_R
48 RSVD 71 CEC
49 RSVD 72 PB_DET
50 SYS_FAN 73 PS_ON#
51 UART_RXD 74 PWR_STATUS
52 UART_TXD 75 GND
53 GND 76 GND
54 StdA_SSRX- 77 GND
55 StdA_SSRX+ 78 GND
56 GND 79 GND
57 StdA_SSTX- 80 GND
