NDiS M535 User Manual
Chapter 2: Jumpers and Connectors
Reset Button
Connector location: SW2
Pin Definition
1 GND
2 RST_BTN#
3 GND
Mic-in Connector
Connector type: 3.5mm TRS
Connector location: CN11
Pin Definition Pin Definition
1 GND 2 GND
3 MIC_IN_R 4 MIC_IN_L
5 JD
