Nexcom NDiS M535 - Internal Connectors; SATA Connector (7-Pin and 15-Pin); RTC Battery Connector

Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
16
NDiS M535 User Manual
Chapter 2: Jumpers and Connectors
Pin Definition Pin Definition
S1 GND S2 SATA_TXPO_C
S3 SATA_TXNO_C S4 GND
S5 SATA_RXNO_C S6 SATA_RXNO_C
S7 GND P1 NC
P2 NC P3 NC
P4 GND P5 GND
P6 GND P7 VCC5
P8 VCC5 P9 VCC5
P10 GND P11 NC
P12 GND P13 SATA_V12
P14 SATA_V12 P15 SATA_V12
MH1 GND MH2 GND
Internal Connectors
SATA Connector (7-pin and 15-pin)
Connector type: Standard Serial ATA 7P and 15P
Connector location: CN2
S1P15
RTC Battery Connector
Connector type: 1x2 2-pin header JST, 1.25mm pitch
Connector location: J6
Pin Definition Pin Definition
1 GND 2 VBAT1
MH1 GND MH2 GND
1 2
