Page 10/112 INTRODUCTION
As for all NEXO systems, GEO S12s are controlled, powered and monitored by dedicated NEXO
TDControllers:
• GEO S12 TDController is based on PS analogue TDController design, and provides full control
for RS15 subwoofer in omnidirectional mode associated to Geo S12. It has 2 analogue inputs
(Left and Right) and 3 analogue outputs (RS15 Mono Omni, GeoS12 Left and GeoS12 Right);
• NX242-ES4 Digital TDController provides comprehensive control of GEO S12 loudspeakers in
multiple configurations. It allows Ethersound
TM
digital audio networking, as well as remote control
for all units in the network. It has 2 analogue / 4 digital inputs and 4 analogue / 4 digital outputs;
IMPORTANT
NX242 must be equipped with NX-Tension Card (ES4 or CAI) to access GEO S12 setups
• NXAMP4x1 and NXAMP 4x4 are Powered Digital Controllers, providing full control and
amplification for RS15 in multiple configurations. Both devices feature 4 analogue inputs and 4
speaker outputs. When equipped with optional card, 4 digital inputs in Ethersound
TM
digital audio
network format as well as remote control for all units in the network become available.
For a complete description of these controllers, please refer to User Manuals. The NX242 and NXAMP
DSP algorithms and parameters are fixed in software and updated regularly: Please consult the NEXO
web site (www.nexo.fr
) for the latest software releases.
GeoD Passive mode
Crossover 80Hz
