Nexo GEO S12 Series User Manual

TECHNICAL SPECIFICATIONS Page 85/112
13 TECHNICAL SPECIFICATIONS
13.1 GEO S1230 Module
13.1.1 System specifications
PRODUCT FEATURES GEO S1230
Components HF: 1 x 3” voice coil, 1.4” throat 16 Ohms driver on a 5° hyperboloid reflective wavesource.
LF: 1 x 12” (30cm) high excursion neodymium 16 Ohm driver.
Height x Width x Depth 344 x 675 x 400 mm (13
1/2
” x 26
1/2
” x 15
1/2
”) excluding accessories
Rigging axis to axis height: 345mm (13
1/2
”)
Shape 30° Trapezoid.
Weight: net 26.8 kg (59.1 lbs) excluding accessories.
Connectors 2 x NL4MP SPEAKON 4 pole (In & Through)
Construction Baltic birch ply with structured black coating.
Front finish Molded Dark Grey Metal Grill.
Flying points Two plates connecting with external accessories.
Intercabinet angle adjustments = (16°) - 22.5° - 30°
SYSTEM SPECIFICATIONS GEO S1230 with NX242 TDcontroller & NX-tension Card
Frequency response [a] 53 Hz – 19 kHz ± 3 dB
Usable range @-6dB [a] 50 Hz – 20 kHz
Sensitivity 1W @ 1m [b] 103 dB SPL nominal
Peak SPL @ 1m [b] 131 to 133dB Peak (for 500 to 900 W RMS Amplifier)
Dispersion [c] Coupling Plane: 28.5°.
Non-Coupling Plane: Configurable 80° / 120°.
Crossover frequencies LF-HF: 1.1 kHz Passive or Active (internally configurable)
Nominal impedance HF: 16 Ohms; LF : 16 Ohms;
Recommended amplifiers
3 GEO S1230 in Parallel
HF: 875 to 1550 Watts into 4 Ohms
LF: 1750 to 3100 Watts into 4 Ohms
4 GEO S1230 in parallel
HF: 1000 to 1800 Watts into 4 Ohms
LF: 2000 to 3600 Watts into 4 Ohms
6 GEO S1230 in parallel
HF: 1650 to 3000 Watts into 2 Ohms
LF: 3300 to 6000 Watts into 2 Ohms
SYSTEM OPERATION
Electronic controller The NEXO TDcontrollers presets are precisely matched to the GEO S12 Series cabinets and include sophisticated
protection. Using GEO S12 Series cabinets without a properly connected NEXO TDcontrollers will result in poor sound
quality and can damage components.
Sub-bass CD18 / GEO SUB / S2 extend system low frequency response down to 32 Hz / 38 Hz / 32 Hz
Speaker cables Active:; 1
-
/1
+
:LF; 2
-
/2
+
: HF
Passive: 1
-
/1
+
: Not Connected; 2
-
/2
+
:LF + HF.
Accessories Please refer to the GEO S12 user manual before any operation.
As part of a policy of continual improvement, NEXO reserves the right to change specifications without notice.
[a] Response curves and data: anechoic far field above 200 Hz, half-space anechoic below 200 Hz.
[b] Sensitivity & peak SPL: will depend on spectral distribution. Measured with band limited pink noise.
Refers to the specified +/- 3 dB range. Data are for speaker + processor + recommended amplifier combinations.
[c] Directivity curves and data: 1/3 octave smoothed frequency response, normalized to on-axis response. Data obtained by computer processing of off-axis
response curves.
[d] Please refer to the GEO S12 user Manual.
Usable range data: frequency response capability with TD crossover slopes removed.
