Nexo GEO S12 Series User Manual

CONNECTION DIAGRAMS Page 21/112
5.3 GEO S12 / ALPHA S2 / NX242-ES4 (Stereo passive mode)
AMPLIFIER 1
AMPLIFIER 2
GEOS12
LEFT
STEREO
IN
TO AMPLIFIERS
STEREO
FROM AMPLIFIERS
GEOS12 LEFT
GEOS12 RIGHT
+ 4 - + 3-
STEREO
GEOS12 STEREO MODE
WITH S2 SUB STEREO
SUB
RIGHT
SUB
LEFT
Speakon 4
SUB LEFT
SUB RIGHT
+ 2 - + 1 -
1 (+) / 1 (-) VLF
2 (+) / 2 (-) N.C.
Speakon 4
Speakon 4
Speakon 4
Speakon 4
1 (+) / 1 (-) N.C.
2 (+) / 2 (-) FULL RANGE
GEOS12
RIGHT
Speakon 4
1 (+) / 1 (-) VLF
2 (+) / 2 (-) N.C.
