Hydraulic principles for NIBE Solar Split FP215P/PL
-EP30
-BT24
-EP30
-BT54
-EP30
-BT55
-GP31
-RM1
-GP15
-QN50
-EB100
-EB101
-CP1
-CM1
-EP30-BT53
-EP8
-CM5
-GP4
-QM45
-RM1
-QM43
-QM44
-RM2
T
T
-FL4
P
-XD1
-GP30
-AA25
-EP30
(T1)
(T2)
(T3)
(T4)
NOTE
This is an outline diagram. Actual installations must be planned according to applicable standards.
Abbreviations
Control unitAA25
(T4)Temp.sensor, dockingBT24
(T1)Temp.sensor, solar panelBT53
(T2)Temp.sensor, solar coilBT54
(T3)Temp.sensor, solar peakBT55
Expansion vessel, heating mediumCM1
Expansion vessel, solarCM5
Buffer vessel solar UKVS 230CP1
NIBE SPLIT indoor section ACVMEB100
NIBE SPLIT outdoor section AMSEB101
Solar panelEP8
Solar kit SCU 10EP30
Safety valve, solarFL4
Circulation pump, solarGP4
Charge pumpGP15
Pump station SPS 10, SPS 20GP30
Pump station MCU 10GP31
Shut-off valveQM4X
Control valveQN50
Non-return valveRMX
Connection box (SRB 22)XD1
NIBE™ SPLIT ACVM 27030
For the Installer
Pipe installation
