ACVM 270
2050 mmRequired ceiling height
600 mmWidth
660 mmDepth
140 kgWeight
230 V 1AC 50 Hz orElectrical connections
400 V 3NAC 50 Hz
069 159 / 069 162Part no.
128AMS 10
Twin RotaryCompressor
25–85 Hz (rps)20–81 Hz (rps)Speed, heating
20–80 Hz (rps)20–86 Hz (rps)Speed, cooling
4380 m
3
/h3000 m
3
/hMax fan flow (heating, nominal)
86 WFan rating
ReversingDefrosting
integratedintegratedDrain pan heater
120 W100 W
4.15 MPa (41.5 bar)Breaking value high pressure
0.079 MPa (0.79 bar)Cut-out value low pressure (15 s)
845 mm750 mmHeight
970 mm780 mm (+67 mm valve
protection)
Width
370 mm (+80 mm with
foot rail)
340 mm (+110 mm with
foot rail)
Depth
74 kg60 kgWeight
Dark grayColour (two coats powder coating)
5 core 2.5 mm
2
Power and communication connection from indoor module
2.90 kg2.55 kgRefrigerant volume (R410A)
30 m*Max. length, refrigerant pipe, one way
Bottom / right-hand side
/ rear side
Right-hand sidePipe connection option
064 110064 033Part no.
*If the length of the refrigerant pipes exceeds 15 m extra refrigerant must be filled at 0.06 kg/m.
Performance, ACVM 270 and AMS 10-8
MaxNominalMinOutd. temp: / Supply
temp.
Heating
8.16/1.98/4.136.19/1.41/4.401.75/0.50/3.507/35 °C (floor)
EN14511 ΔT5K Output/input/COP
5.68/1.70/3.345.48/1.51/3.631.49/0.48/3.122/35 °C (floor)
5.53/2.06/2.694.04/1.45/2.791.04/0.45/2.31-7/35 °C (floor)
3.92/1.69/2.322.74/1.18/2.321.25/0.59/2.10-15/35 °C (floor)
7.81/2.47/3.166.00/1.72/3.502.64/0.81/3.277/45 °C
6.64/2.54/2.614.80/1.77/2.722.14/0.79/2.712/45 °C
5.17/2.35/2.203.74/1.64/2.281.46/0.75/1.95-7/45 °C
3.83/2.08/1.842.68/1.40/1.910.92/0.69/1.33-15/45 °C
7.36/2.73/2.706.09/2.22/2.753.08/1.26/2.457/55 °C
4.64/2.66/1.743.33/2.00/1.661.88/1.14/1.65-7/55 °C
